This energy saver switch can be used on TThotel system only.
This energy saver switch support to get power by insert room card, or by TThotel app.
With gateway, the switch can be remotely powered on/ off on TThotel software;
This energy saver switch can be installed in 86 box.
TThotel
This energy saver switch can be used on TThotel system only.
The switch supports to be activated by card, TThotel app and remotely power on/off;
When the guest get out the room, they take out the cards, then the room will power off. In this way, the hotel can save much electricity.
It has three working mode:
1) Any card mode: any card can be used to get power.
2) Hotel card mode: only the hotel card can be used to get power. The card has been encrypted.
3) Room card mode: only the matched room card can be used to get power. It can prevent the abuse of electricity by cleaning staff。
| Model | ES3 |
|---|---|
| Material | PC plastic |
| Working mode | Any card switch; Hotel card switch; Hotel room card switch; |
| Card frequency | 13.56mhz mifare card |
| Remotely power on/off | Support (need connect to gateway) |
| Loaded current | 40A |
| Loaded power | 8800W |
| Working voltage | AC85-265V |
| Wireless frequency | 802.11b/g/n 2.4GHZ |
| Delay time | 15s |
| Installation | 86 box (25mm depth, 60mm hole distance) |
This energy saver switch can be used on TThotel system only.
When guest get in the room, put the card inside the switch, then the room will get power.
When the guest get out the room, they take out the cards, then the room will power off. In this way, the hotel can save much electricity.
It has three working mode:
1) Any card mode: any card can be used to get power.
2) Hotel card mode: only the hotel card can be used to get power. The card has been encrypted.
3) Room card mode: only the matched room card can be used to get power. It can prevent the abuse of electricity by cleaning staff。
